AC-DC 5V/2A 10W Power Module
Fuente de alimentación 85 - 265 VAC / 5 VDC 2A, una potencia de 10W y una eficiencia del 80%.
COD: TROOPM1070
Peso: 0.010 Kg
Disponibilidad: Sin Stock
ARS 14222.00
El producto no está disponible para la venta en este momento
Características
Product Description
This power supply is fully isolated industrial internal power module with temperature protection, overcurrent protection and short circuit full protection, AC85 ~ 265V wide voltage input, high and low voltage isolation.
Features:
- Input (full load): AC 85-265V or DC 100v-370v
- Input current (full load): 0.027A (AC110V) 0.0136A (AC220V)
- Input inrush current (full load): 20A
- Output: 5V, 0-2A, 2.2A max, output voltage range 4.8-5.2V, 60mV voltage ripple
- DC output power: 10W
- Efficiency: 80%
- On/off overload range: 10%
- Output upward time: 100ms
- Size: 6.6*3.0*2.1
