DC Toy / Hobby Motor - 130 Size

DC Toy / Hobby Motor - 130 Size

Motor DC tamaño 130, muy compacto, con rango de alimentación de 4.5V a 9V.

COD: ERMS13001M

Peso: 0.017 Kg

Disponibilidad: Sin Stock

Su correo electrónico:

ARS 107.00

Cantidad:

El producto no está disponible para la venta en este momento

Características

Description:

This is a standard '130 size' DC motor. It comes with a wider operating range than most toy motors: from 4.5 to 9VDC, This range makes them perfect for controlling with most of the Arduino Motor Shield, or with an Arduino where you are more likely to have 5 or 9V available than a high current 3V setting.

If you find it hard to fix this motor in your project, you can have a look at the 130 DC Motor Bracket, hope it helps for you.



Specification:

  • Operating Temperature: -10°C ~ +60°C.
  • Rated Voltage: 6.0VDC.
  • Rated Load: 10 g*cm.
  • No-load Current: 70 mA max.
  • No-load Speed: 9100 ±1800 rpm.
  • Loaded Current: 250 mA max.
  • Loaded Speed: 4500 ±1500 rpm.
  • Starting Torque: 20 g*cm.
  • Stall Current: 500mA max.
  • Body Size: 27.5mm x 20mm x 15mm.
  • Shaft Size: 8mm x 2mm diameter.
  • Weight: 17.5 grams.
